Features

Danfoss 100 /100plunger pump /motor power configuration makes walking fast and powerful.
The famous 260-horsepower national iv engine has strong power, sufficient reserves, and forward and reverse functions to prevent high temperatures.
Grain unloading height 4.8 m+，grain unloading time 2.5 min， fast and efficient.
Threshing and cleaning 1.3 m， the food is clean and the food loss rate is low.
Open type, large capacity granary, effective volume >7.5m³。
Fully electronically controlled operation, electronically controlled armrest, and suspended seat.
Bearings, belts and chains are of famous brands.
Equipped with three-speed gearbox and mechanical four-wheel drive.

Project	Unit	Parameter
Model name	/	4YZL-6 self-propelled corn grain combine harvester
Structural type	/	■wheeled □crawler ■picking ears □peel ■harvesting the seeds directly □returning straw to fields □straw recycling □straw baling
Supported engine model specifications	/	YCA07P260-T400（ national iv)
Matching engine rated power	kw	191
Matched engine rated speed	r/min	2200
Overall dimensions of the machine (length ×width ×high)	mm	10500×4200×3900 / 10500×4300×3900
Overall machine quality	kg	12000 / 12500
Line spacing	mm	470-530 / 620-680
Working width	mm	3970 / 4100
Minimum ground clearance	mm	390
Working speed	km/h	1.05-7
Job hour productivity	k㎡/h	1.1-1.5
